25
INSTALLER
USER
MAINTENANCE TECHNICIAN
1.16 SEPARATOR KIT INSTALLATION.
Type C conguration, sealed chamber and fan assisted.
Separator kit Ø 80/80.
is kit allows air to come in from outside the building and the
exhaust to exit from the chimney, ue or intubated duct through
divided ue exhaust and air intake pipes. Combustion products
are expelled from pipe (S) (in plastic, so as to resist acid con-
densate). Air is taken in through duct (A) for combustion (this
is also in plastic). e intake pipe (A) can be installed either on
the right or le hand side of the central exhaust pipe (S). Both
ducts can be routed in any direction.
Kit assembly (Fig. 21):
install ange (4) on the central hole of the boiler, positioning
gasket (1) with the circular projections downwards in contact
with the boiler ange, and tighten using the hex screws with
at tip contained in the kit. Remove the at ange present in
the lateral hole with respect to the central one (according to
needs) and replace it with the ange (3), positioning the gasket
(2) already present in the boiler and tighten using the supplied
self-threading screws. Fit the male side (smooth) to the bends (5)
in the female side of the anges (3 and 4). Fit the intake terminal
(6) with the male side (smooth) in the female side of the bend
(5) up to the end stop, ensuring that the internal and external
wall sealing plates are tted. Fit the exhaust pipe (9) with the
male end (smooth) to the female end of the bend (5) up to the
end stop; making sure that the internal wall sealing plate has
been tted, this will ensure sealing and joining of the elements
making up the kit.
Installation clearances (Fig. 22).
e minimum installation clearance measurements of the Ø
80/80 separator terminal kit have been stated in some limit
conditions.
Extensions for separator kit Ø 80/80.
e maximum vertical straight length (without bends) that
can be used for Ø 80 intake and exhaust pipes is 41 metres, re-
gardless from whether they are used for intake or exhaust. e
maximum horizontal straight length (with bend in suction and
in exhaust) that can be used for Ø 80 intake and exhaust pipes
is 36 metres, regardless from whether they are used for intake
or exhaust. Please note the type of installation C
43
must be done
with a natural draught ue.
N.B.: to favour the removal of possible condensate forming in the
exhaust pipe, tilt the pipes towards the boiler with a minimum
slope of 1.5% (Fig. 23).
