1.17 ADAPTOR C9 KIT INSTALLATION.
is kit allows an Immergas boiler to be installed in “C
93
” cong-
uration, with combustion air intake directly from the sha where
the ue gas exhaust is, obtained by means of a ducting system.
System composition.
e system must be combined with the following components
(sold separately) to be functional and complete:
-
kit C
93
Ø 100 or Ø125 version;
-
rigid ducting Ø 60 and Ø 80 and exible Ø 50 and Ø 80 kit;
-
ue exhaust kit Ø 60/100 or Ø 80/125 congured according to
the installation and type of boiler.
Kit Assembly.
-
Mount the components of kit “C9” on the door (A) of the ducting
system (Fig. 25).
-
(Version Ø 125 only) mount the anged adaptor (11) interposing
the concentric gasket (10) on the boiler, tting it with the screws
(12).
-
Mount the ducting system as described in the relative instruc-
tions che.
- Calculate the distances between the boiler drain and the bend
of the ducting system.
-
Prepare the boiler ue system, making sure that the internal pipe
of the concentric kit is tted up to the end stop in the ducting
system curve (Quota “X” Fig. 26), whereas the external pipe must
reach the end stop of the adapter (1).
N.B.: to encourage the removal of possible condensate forming
in the exhaust pipe, tilt the pipes towards the boiler with a min-
imum slope of 1.5%.
-
Mount the cover (A) complete with adaptor (1) and caps (6) on
the wall and assemble the ue system to the ducting system.
N.B.: (version Ø 125 only) before assembly check the gaskets are
in the right position. In the event component lubrication (already
carried out by the manufacturer) is not sucient, remove the
residual lubricant using a dry cloth, then to ease tting coat the
parts with common or industrial talc.
Once all components have been assembled properly, the exhaust
fumes will be expelled via the ducting system; the combustion
air for normal boiler operation will be aspirated directly by the
sha (Fig. 26).
Kit composition:
Ref. Qty Description
1 1 Door adaptor Ø 100 or Ø 125
2 1 Door gasket made of neoprene
3 4 Screws 4.2 x 9 AF
4 1 Hex headed screw M6 x 20
5 1 Flat nylon washer M6
6 2 Door hole closure metal-sheet
plate plug
7 1 Plug gasket made of neoprene
8 1 Toothed washer M6
9 1 Nut M6
10 1 (kit 80/125) Concentric gasket Ø 60-100
11 1 (kit 80/125) Flanged adapter Ø 80-125)
12 4 (kit80/125) Hex headed screws M4 x 16 slotted
- 1 (kit 80/125) Bag of lubricating talc
Installation drawings key:
Unique identication of the component in
the kit
Identication of the component not supplied
in this kit
1
A
Supplied separately:
Ref. Qty Description
A 1 Ducting kit door
Rigid Ø 80
ducting
(A) mm
SHAFT
(B) mm
SHAFT
(C) mm
86 126 146
Flexible Ø 80
ducting
(A) mm
SHAFT
(B) mm
SHAFT
(C) mm
90 130 150
Ducting
Ø 60 Rigid and
Ø 50 Flexible
(A) mm
SHAFT
(B) mm
SHAFT
(C) mm
66 106 126
