13 Restart attempts 0 to 10 — 1 0
14 Restart mode 0 = Inactive; no restart — — 0
LU indication on V loss
1 = Inactive; no restart
LU indication on I/P voltage recovery
2 = Active; restart at same O/P frequency
as when trip occurred.
3 = Active; restart at 0Hz
15 Electronic thermal (Motor 1) — — 2
overload 1 — mode 0 = Inactive
(for Electronic thermal o/l 2 1 or 3 = Active (standard 4-pole motors)
see F66/67) 2 or 4 = Active (inverter-rated motors)
16 Electronic thermal (Motor 1) 0.01 to 99.9 0.01 to 9.99 A 0.01 *
overload 1 — level 10.0 to 99.9 0.1
0.01 to 99.9 = 20% to 105% of inverter rated current
* Default factory-set at rated current for a 4-pole standard motor for each inverter frame size.
17 DC injection braking 0 = Inactive — — 0
— mode 1 = Active
18 DC injection braking 0 to 60 Hz 1 0
— starting frequency NOTE 0 = 0.2Hz
19 DC injection braking 0 to 100 % 1 50
— level Percent of inverter rated current
20 DC injection braking 0 to 30 0.00 to 9.99 s 0.01 0.5
— time 10.0 to 30 0.1
21 Preset speed 1
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
22 Preset speed 2
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
23 Preset speed 3
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
24 Preset speed 4
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
25 Preset speed 5
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
26 Preset speed 6
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
27 Preset speed 7
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
28 S-ramp accel./decel. 0 = Inactive; linear accel. and decel. — — 0
— selector
1 = Active; quick S-ramp
2 = Active; slow S-ramp
Function
Setting Range Unit Resol. Def.
No. Name
Functions in can be adjusted while the inverter is running. Data in […] applies to three phase inverters.
Resol. = resolution; Def. = Factory-set default — refer to Function 39.
22
