Function
Setting Range Unit Resol. Def.
No. Name
Functions in can be adjusted while the inverter is running. Data in […] applies to three phase inverters.
Resol. = resolution; Def. = Factory-set defaults — refer to Function 39.
23
29 Protection history Last 4 protection trips, last trip first — — —
30 Starting frequency 0 to 15 Hz 1 1
NOTE 0 = 0.2Hz
31 Torque limit 0 = No limit % 1 0
— accel./decel. 20 to 180 = Limit active
32 Torque limit 0 = No limit % 1 0
— constant speed 20 to 180 = Limit active
33 Braking torque 0 = Low (when no dynamic brake resistor) — — 0
— selector 1 = High (with dynamic brake resistor)
34 Bias frequency -400 to +400 Hz 1 0
35 Input frequency reference 0 to 250 0.00 to 9.99 % 0.01 100.0
— gain 10.0 to 250.0 0.1
36 Frequency limiter — high 0 to 400 Hz 1 70
37 Frequency limiter — low 0 to 400 Hz 1 0
38 O/P current stability 0 to 10 — 1 5
39 Data initialisation 0 = Hold custom settings — — 0
1 = Reinstate factory-set default values
40 Terminals FMA/FMP 0 = FMA output (analog signal) — — 0
— selector 1 = FMP output (digital pulse signal)
41 Terminal FMA 0 = Output frequency — — 0
— function 1 = Output current
2 = Output torque
3 = Load factor
42 Terminal FMP 10 to 100 — 1 24
— pulse rate multiplier
43 Terminal X4 0 = Command I/P for accel./decel. 2 — — 0
— functions 1 = Fourth I/P allowing 15 Preset speeds
2 = Command I/P for base freq. 2
3 = ‘Hold’ signal (latch for 3-wire I/P)
44 Preset speed 8
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
45 Preset speed 9
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
46 Preset speed 10
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
47 Preset speed 11
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
48 Preset speed 12
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
Preset Speeds 13, 14, 15 overleaf
