49 Preset speed 13
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
50 Preset speed 14
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
51 Preset speed 15
0 to 400 0.00 to 99.99 Hz 0.01 0.00
100 to 400 0.1
52 Frequency reference filter 0.02 to 5.00 s 0.02 0.06
53 Operation timer 0.00 = Inactive — — 0.00
0.01 to 3600 0.01 to 9.99 s 0.01
10.0 to 99.9 0.1
100 to 999 1
1000 to 3600 10
54 Terminal Y1E 0 = Inverter running — — 1
— functions 1 = Freq. level (FDT) detection
2 = ‘At Speed’ signal (FAR)
3 = Undervoltage trip activated (LU)
4 = Torque limit activated (TL)
5 = Auto-restart after power loss (IP)
55 Frequency detection 0 to 400 0.00 to 99.99 Hz 0.01 50.00
— FDT level 100 to 400 0.1
56 Hysteresis bandwidth 0 to 30 Hz 1 10
— for FDT & FAR
57 Terminal THR 0 = THR external trip function — — 0
— function 1 = Data protection lock
58 Skip frequency 0 to 30 Hz 1 3
— hysteresis
59 Skip frequency 1 0 to 400 Hz 1 0
60 Skip frequency 2 0 to 400 Hz 1 0
61 Skip frequency 3 0 to 400 Hz 1 0
62 Base frequency 2 (Motor 2) 15 to 400 Hz 1 50
(for Base freq. 1 see F04)
63 Acceleration time 2 0 to 3600 0.00 to 9.99 s 0.01 10.0
64 Deceleration time 2 0 to 3600 10.0 to 99.9 s 0.1 10.0
100 to 999 1
(for Acc,/Dec. 1 see F06/07) 1000 to 3600 10
65 Torque boost 2 (non-auto) 1 = Squared characteristic (for pumps — 1 13
NOTE Only if and fans)
Function 43 = 2 2 = Proportional characteristic
3 = Low linear boost…
…increasing in units steps to…
(for Torque boost 1 see F08) 31 = High linear boost
Function
Setting Range Unit Resol. Def.
No. Name
Functions in can be adjusted while the inverter is running. Data in […] applies to three phase inverters.
Resol. = resolution; Def. = Factory-set default — refer to Function 39.
24
