66 Electronic thermal (Motor 2) — — 0
overload 2 — mode 0 = Inactive
(for Electronic thermal o/l 1 1 or 3 = Active (standard 4-pole motors)
see F15/16) 2 or 4 = Active (inverter-rated motors)
67 Electronic thermal (Motor 2) 0.01 to 99.9 0.01 to 9.99 A 0.01 *
overload 2 — level 10.0 to 99.9 0.1
0.01 to 99.9 = 20% to 105% of inverter rated current
* Default factory-set at rated current for a 4-pole standard motor for each inverter frame size.
68 Slip compensation 0 = Inactive Hz 0.1 0.0
0.1 to 5.0 = Active
69 Torque vector control 0 = Inactive — — 0
1 = Active
70 Motor 1 capacity 0 = One size larger than standard — — 1
(frame size) 1 = Standard frame size for the inverter
2 = One size below
3 = Two sizes below
71 Rated current 1 (Motor 1) 0.01 to 99.9 0.01 to 9.99 A 0.01 *
10.0 to 99.9 0.1
72 No-load current 1 (Motor 1) 0.01 to 99.9 0.01 to 9.99 A 0.01 *
10.0 to 99.9 0.1
73 Rated current 2 (Motor 2) 0.01 to 99.9 0.01 to 9.99 A 0.01 *
10.0 to 99.9 0.1
* Default factory-set at rated current for a 4-pole standard motor for each inverter frame size.
74 Automatic tuning 0 = Inactive — — 0
1 = Active
75 Tuning %R value 0.00 to 50.00 % 0.01 *
76 Tuning %X value 0.00 to 50.00 % 0.01 *
* Default factory-set at rated value for a 4-pole standard motor for each inverter frame size.
77 Torque limiter response 000 to 999 — — 369
— constant speed
78 Torque limiter response 000 to 999 — — 394
— during accel./decel.
79 Option selector 0 = No options installed — — 0
1 = DI option card
2 = DI/O option card
3 = RS option card
Please consult IMO Precision Controls Ltd for details of options.
Function
Setting Range Unit Resol. Def.
No. Name
Functions in can be adjusted while the inverter is running. Data in […] applies to three phase inverters.
Resol. = resolution; Def. = Factory-set defaults — refer to Function 39.
25
