IMO Precision Controls K7 Series User Manual

Chapter 7 Usage of Functions
7-
５４
6) Wiring
(1) Caution for wiring
ሪ
Make sure that external input signal of the mixture module of AC and analog I/O is not affected by induction noise or occurs
from the AC through using another cable.
ሪ
Wire is adopted with consideration about peripheral temperature and electric current allowance. Thicker than Max. size of
wire AWG22 (0.3
᎙
) is better.
ሪ
If wire is put near to high temp. radiated device or contacted with oil for a long time, it may cause of electric leakage so that
it gets broken or miss-operation during wiring.
ሪ
Be sure to connect with care of polarity while connecting to external 24V DC power supply.
ሪ
In case of wiring with high voltage line or generation line, it makes induction failure so then it may cause of miss-operation
and out of order.
(2) Wiring example
儆
) Analog input
喞
) Analog output
*1 : Be sure to use two-core twisted shield wire.
* Be careful to use that analog output is 1 channel.
*
1
I
+
I
−
GND
V
+
V
−
GND
Voltage output
Current output
2K~1
Ꮓ
Less than
510
ᆅ
*1
input
+
-
+
-
input
Voltage input Current input
V0
I0
COM0
V1
I1
COM1
Terminal
*1*1
Terminal
