Chapter8 Communication Function
8-37
గ櫖峲喺殯
:
b7 b6 b5 b4 b3 b2 b1 b0
(4) Status flag of the master PLC
Status Information of master PLC is saved in D4448
b15 b3 b2 b1 b0
- - - - - - - - - - -
b1 : be set in case station is duplicated
b2 : be set in case device area over
(5) Max/min/current sending/receiving cycle of set parameter
Contents: the interval between after sending and before receiving
Item Saved area
Max. D4449 – D4450
Min. D4451 – D4452
Current D4453 – D4454
Error status of slave PLC
1 : Error
0 : Normal
Not used
Operation mode of slave PLC
b4 : STOP
b5 : RUN
b6 : PAUSE
b7 : DEBUG
D4448
