Chapter 7 Usage of Various Functions

౎

(3) 2-phase operation mode (1 Multiplication Operation : D4999 = h2011)

U/D : set automatically by the phase difference between A and B phase

PR : set by external PR input

Multiplication : 1

Ladder diagram

Time chart

HSC

U/D PV 00100

PR SV 01000

MOV h2011 D4999

M000

hase

ulse in

B-

hase in

(

U/D

)

Current value of HSC 10 12 13 14 13 12 1111

F012

M001

M002
