Chapter 7 Usage of Various Functions
7-
౏
4) 2-phase operation mode (2 Multiplication Operation : D4999 = 2012)
U/D : set automatically by the phase difference between A and B phase
PR : set by external PR input
Multiplication : 2 times
Ladder diagram
Time chart
HSC
EN
U/D PV 00100
PR SV 01000
MOV h2012 D4999
M000
A
-
p
hase
p
ulse in
p
ut
B-
p
hase in
p
ut
(
U/D
)
Current value of HSC 10 12 13 14 15 16 17
18
17 16 15 14 13 1211
M001
M002
F012
