iDrive2 inverters Function Parameters
48
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
terminals
state at
previous 2
fault
P07.56
Output
terminals
state at
previous 2
fault
0
●
P08 Group Enhanced function
P08.00
ACC time 2
Refer to P00.11 and P00.12 for detailed definition.
IMO XKL series selects four groups of ACC/DEC time
which can be selected by P5 group. The first group of
ACC/DEC time is the factory default.
Setting range:0.0~3600.0s
Depend
on model
○
P08.01
DEC time 2
Depend
on model
○
P08.06
Jogging
running
frequency
This parameter is used to define the reference frequency
during jogging.
Setting range: 0.00Hz ~P00.03(the Max. frequency)
5.00Hz
○
P08.07
Jogging
running ACC
time
The jogging ACC time is the time to accelerate from 0Hz
to the Max. Frequency.
The jogging DEC time is the time to decelerate from the
Max. Frequency (P0.03) to 0Hz.
Setting range:0.0~3600.0s
Depend
on model
○
P08.08
Jogging
running DEC
time
Depend
on model
○
P08.15
Traverse
range
This function applies to the applications where traverse
and convolution function are required such as textile and
chemical fibre.
The traverse function means that the output frequency of
the inverter is fluctuated with the set frequency as its
center. The route of the running frequency is illustrated
as below, of which the traverse is set by P08.15 and
when P08.15 is set as 0, the traverse is 0 with no
function.
0.0%
○
P08.16
Sudden
jumping
frequency
range
0.0%
○
P08.17
Traverse
boost time
5.0s
○
P08.18
Traverse
declining
time
5.0s
○
