5 Function Parameters
The function parameters of iDrive2 XKL series inverters have been divided into 30 groups (P00~P29) according to
the function, of which P18~P28 are reserved. Each function group contains certain function codes applying 3-level
menus. For example, “P08.08” means the eighth function code in the P8 group function, P29 group is factory
reserved, and users are unable to access these parameters.
For simplicity of function codes setting, the function group number corresponds to the first level menu, the function
code corresponds to the second level menu and the function code corresponds to the third level menu.
Parameter Menu.
Menu
Sub Menu
Description
Examples of Functions
P00
P00.00 – P00.18
Basic parameters
Run command type, Max frequency, ramp times
P01
P01.00 – P01.24
Start/Stop control
DC injection braking, coast to stop, delay start, auto restart
P02
P02.00 – P02.27
Motor 1 settings
Motor ratings, Kw, Current, speed
P04
P04.00 – P04.24
V/F control
Torque boost, slip compensation, V/F curve
P05
P05.00 – P05.41
Input terminals
Set function of digital inputs S1-S5
P06
P06.00 – P06.21
Output terminals
Set function of relay, transistor and analogue outputs
P07
P07.00 – P07.56
Keypad/HMI settings
Set user password, quick key function and display
P08
P08.00 – P08.50
Enhanced functions
Jogging, cooling fan and dynamic braking functions
P09
P09.00 – P09.13
PID control settings
PID, SV and feedback source settings
P10
P10.00 – P10.32
Pre-set speeds & PLC
Pre-set speed values & PLC selection
P11
P11.00 – P11.13
Protective functions
Set protective function trip/output levels
P14
P14.00 – P14.06
Comms settings
Baud rate, check bits and other Modbus/RS485 settings
P17
P17.00 – P17.37
Monitoring
Monitor live values of inverter during operation
1. Below is the instruction of the function lists:
The first column “Function code”: code of function parameter group and parameters；
The second column “Name”: full name of function parameters；
The third column “Detailed illustration of parameters”: Detailed explanation of the function parameters
The fourth column “Default value”: the original factory set value of the function parameter；
The fifth column “Modify”: shows the modification ability of the parameter according to the list:-
“○”: means the set value of the parameter can be modified in stop and running state；
“◎”: means the set value of the parameter can only be modified in stop state；
“●”: means the value of the parameter is the real detection value which can not be modified.
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P00 Group Basic function group
P00.00
Speed
control mode
2:PWM control (suitable for AM)
2 is suitable in cases where it does not need high control
accuracy, such as the load of fan and pump. One
inverter can drive multiple motors.
2
◎
