iDrive2 inverters Function Parameters
61
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P11.13
Output
terminal
action
selection
during fault
Select the action of fault output terminals on
undervoltage and fault reset.
0x00~0x11
LED ones:
0:Action under fault undervoltage
1:No action under fault undervoltage
LED tens:
0:Action during the automatic reset
1:No action during the automatic reset
0x00
○
P14 Group Serial communication
P14.00
Local
communicati
on address
The setting range:1~247
When the master is writing the frame, the
communication address of the slave is set to 0; the
broadcast address is the communication address. All
slaves on the MODBUS fieldbus can receive the frame,
but the slave doesn’t answer.
The communication address of the drive is unique in the
communication net. This is the fundamental for the point
to point communication between the upper monitor and
the drive.
Note: The address of the slave cannot be set to 0.
1
○
P14.01
Baud rate
Set the digital transmission speed between the upper
monitor and the inverter.
0:1200BPS
1:2400BPS
2:4800BPS
3:9600BPS
4:19200BPS
5:38400BPS
Note: The baud rate between the upper monitor and the
inverter must be the same. The higher the baud rate, the
faster the communication speed.
4
○
P14.02
Digital bit
checkout
setting
The data format between the upper monitor and the
inverter must be the same.
0: No check (N,8,1) for RTU
1:Odd check (E,8,1) for RTU
2:Even check (O,8,1) for RTU
3:No check (N,8,2) for RTU
1
○
