Programmable controller PI 6000
46
Read parameters C0pa
Output: 11 digits decimal, addresses also hex
DD.........: Pyrometer unit address (FF = no pyrom.)
..D........: Alarm pyrometer settling time (cf. ez)
...0.......: Always 0
....D......: Controller output (cf. Ya)
.....D.....: Alarm pyrometer analogue input (cf. is)
......0....: Always 0
.......C0..: PI 6000 unit address (always C0)
.........D.: Baud rate PI 6000 ↔ Pyrometer (cf. br)
..........D: Button inhibit (cf. lk)
Unit type / software
version
C0ve Output: VVMMYY VV = 81 (identification PI 6000)
MM = Month YY = Year (date of the software in the
unit)
Unit number C0sn Output: DDDDD 5-digit decimal
Reference number C0bn Output: XXXXXX 6-digit hexadecimal
e.g.: 3A634E = 3 826 510
Software version C0vs Output: DD.MM.YY XX.XX
DD = Day MM = Month YY = Year
XX.XX = Version number for the software in the unit
°C/°F setting C0fhX X = 0 sets °C; X = 1 sets °F
9 Reference numbers
3 826 510 PI 6000 for front panel mounting
3 828 210 Table-top housing TG 6P (for the installation of the PI 6000) incl. power supply and 5 m
pyrometer cable)
10 Transport, packaging, storage
The unit may be damaged or rendered unusable by improper transport. If the original packaging is no longer
available, a cardboard box filled with PE material to absorb any knocks is to be used for transporting the unit.
In case of shipment by sea or for extended storage in high atmospheric humidity, the unit should be pro-
tected against moisture in a sealed plastic bag (if necessary add silica gel).
The PI 6000 is designed for a storage temperature of -20 ... 70°C. Storage above or below this temperature
may result in damage or malfunctions.
11 Maintenance
11.1 Safety
Take care during maintenance work or when programming the PI 6000 or the pyrometer. If the units are
integrated into processes in a plant, these processes should be shut down as necessary and secured
against switching back on. Then the maintenance work can be performed on the pyrometer.
11.2 General
The unit does not have any parts that require maintenance. Only clean the front panel with a dry cloth as
required.
In addition, the pyrometer lens must be kept clean for correct measurement. In case of soiling, the lens can be
cleaned with a soft cloth in conjunction with alcohol. You can also use commercially available tissues for
cleaning spectacles or photographic lenses (do not use any acid agents or solvents).
