Impulse RT750 - Page 18

─ 18 ─
Parts List and Exploded View
Console ASSY
Item No.
Grade No. Part No. Description QTY
1 7.1 RT7505100 Back Cover Of Console 1
2 7.2 RT7505200 Neck Front Cover 1
3 7.3 RT7502600 Bracket For Console 1
4 7.4 RT7508400 Upper Block For Back Cover Of Console 1
5 7.5 RT75006ASSY Front Cover Of Console ASSY 1
6 7.6 RT7505300 Neck Back Cover 1
7 7.7 GB845ST4.2*13DS Phillip Screw ST4.2*13 7
8 7.8 GB70M6*10DS2 Socket Head Cap Screw M6*10 2
9 7.9 GB818M5*15DS2 Phillip Screw M5*15 10
