Impulse RT750 - Page 20

─ 20 ─
Parts List and Exploded View
Mainframe ASSY
Item No.
Grade No. Part No. Description QTY
33 4.33 RT7002200 Right Front Decorative Cover 1
34 4.34 RT7002100 Left Front Decorative Cover 1
35 4.35 RT7002000 Motor Cover 1
36 4.36 GB17880.3M5*13DS17 Countersunk Head Hexagon Riveted Nuts M5 6
37 4.37 STDP6800 Locknut M8 12
38 4.38 GB17880.5M6*16.5DS17 Flat Head Hexagon Riveted Nuts M6 18
39 4.39 GB17880.3M6*15DS17 Countersunk Head Hexagon Riveted Nuts M6 2
40 4.40 NM8DS2 Locknut M8 1
41 4.41 GB845ST4.2*13DS Phillip Screw ST4.2*13 19
42 4.42 CNLM8*35DHS20NL
Hexagon Socket Countersunk Head Cap Head Screw M8*35
10
43 4.43 PNLM8*60DS20
Hexalobular Socket Pan Head Tapping Screw M8*60
1
44 4.44 DQ8DS2A
Washer Φ9*Φ22*2 6
45 4.45 GB70M8*80*80DHS6 Socket Head Cap Screw M8*80 2
46 4.46 GB5780M8*30DS2NL Hex Head Bolt M8*30 4
47 4.47 GB818M5*20DS2 Phillip Screw M5*20 6
48 4.48 GB936DHS12 Spring Washer Φ6 2
49 4.49 GB818M6*10DHS2 Phillip Screw M6*10 2
50 4.50 GB70M6*20DHS20 Socket Head Cap Screw M6*20 24
51 4.51 GB5780M8*150DS2 Hex Head Bolt M8*150 6
52 4.52 GB70M6*30DS4 Phillip Screw M6*30 6
53 4.53 GB70M6*60DS2 Socket Head Cap Screw M6*60 2
54 4.54 GB5780M10*165*40DS20 Hex Head Bolt M10*165 2
55 4.55 DQ10DS2A Washer Φ11*Φ23*2 6
56 4.56 GB5780M10*180DHS2 Hex Head Bolt M10*180 2
57 4.57 GB6560M4*8DSG Phillip Screw M4*8 3
58 4.58 GB862.24DS12 Serrated Lock Washers Φ4 3
59 4.59 DQXK8.4 U-Shape Wires Clip 2
60 4.60 L500M42816-3 Connect Wire 1
61 4.61 L1600M50-SMA-8 Console Wire Down 1
62 4.62 LD2000 Protective Sleeve 1
63 4.63 SD3*150 Band Cable 4
64 4.64 GB41M10 Nut M10 4
