99903514:TELESCOPIC CRANE: 5-9
SECTION 5: DECALS
NOTICE
70395324
This crane has been manufactured
in accordance with ASME B30.5,
Mobile and Locomotive Cranes.
Figure E-20
DECAL: ASME B30.5
PART NUMBER: 70395324
FUNCTION: To inform operator and maintenance
personnel of the specification to which the crane was
manufactured.
USED ON: All cranes.
PLACEMENT: On crane base.
QUANTITY: 1
Figure E-21
DECAL: Load Block Rating
PART NUMBER: Depends on load block
70396546 - 1.0 tons
70396547 - 1.2 tons
70396548 - 1.6 tons
71394083 - 2.0 tons
71394080 - 2.5 tons
71394081 - 3.0 tons
70393860 - 5.5 tons
71394082 - 7.0 tons
FUNCTION: To inform operator of the amount the
load block can lift.
USED ON: All cranes.
PLACEMENT: On the snatch block.
QUANTITY: 2
Figure E-22
DECAL: Hydraulic Oil Reservoir Fill
Recommendations
PART NUMBER: 70394189
FUNCTION: To inform operator and maintenance
personnel of the recommended hydraulic oil to be
used under differing climatic conditions.
USED ON: All cranes.
PLACEMENT: On or near the hydraulic oil reservoir.
QUANTITY: 1
SNATCH BLOCK WEIGHT: 22 POUNDS
20050125
