AM130 - Removing clamping element holder
Orientation
Due to different requirements and/or specifications of the respective
manufacturers, be sure to review the respective manufacturer's
documentation!
The removal tool described below refers to the use of standard collet
clamping. Removal of the clamping element holder is necessary as
part of regular cleaning of the machine. In order to support removal
that is easier on the bearings, INDEX requires the use of a removal
tool for removing the clamping element holder for standard collet
clamping.
To avoid putting strain on the spindle bearings, it should
generally be possible to remove each clamping device in a way
that is easy on the bearings without using a rebound hammer
(Zocker). Therefore, forcing pins or removal tools must be
provided for all clamping devices.
Procedure
1. Loosen and remove mounting screws of clamping element holder.
Maintenance Summary - Care activities
34
Maintenance Instructions
MS40-8
DIM078EN - 02.06.2020
