Procedure
1. Deactivate spindle control on the machine controller.
2.
Caution
Mounting in adjacent holes will damage the encoder
system of the respective spindle, requiring repair and
readjustment.
Always make be sure to mount the locking pin only at the points/
holes marked in red on the respective spindle.
Turn the spindles by hand until the locking pin can be mounted.
3. Be sure to remove the spindle lock (device/locking pin) after finishing
the work.
Maintenance Summary - Care activities
38
Maintenance Instructions
MS40-8
DIM078EN - 02.06.2020
