Relay Output Tab
Relay Output Configuraon ‐ check to enable which control parameters are used to deter‐
mine when the Relay output will be On.
This output provides a Ground when it is On.
Maximum current draw is 1 amp.
Delay Timer ‐ these sengs control the Delay me and On me
for the Relay output.
Valid range ‐ 0.000 to 10.000 in .001 Second increments.
Engine RPM ‐ these sengs control the output based on Engine
RPM.
Valid range ‐ 0 to 16000 in 10 RPM increments.
Stage2 Nitrous Percent ‐ these sengs control the output
based on Stage2 Nitrous Percent.
Valid range ‐ 0.0 to 100.0 in .1 Percent increments.
Stage2 Fuel Percent ‐ these sengs control the output based on
Stage2 Fuel Percent.
Valid range ‐ 0.0 to 100.0 in .1 Percent increments.
Stage1 Nitrous Percent ‐
these sengs control the
output based on Stage1
Nitrous Percent.
Valid range ‐ 0.0 to 100.0
in .1 Percent increments.
Stage1 Fuel Percent ‐ these
sengs control the output
based on Stage1 Fuel Per‐
cent.
Valid range ‐ 0.0 to 100.0
in .1 Percent increments.
