General Overview
Menu bar
Toolbar menu
Hover mouse cursor over icon for
informaon.
Tabbed navigaon buons
Progress bar– this pro‐
vides visual feedback for
read and write operaons
to the controller through
the USB interface.
USB connecon status– this
indicates a valid USB connec‐
on has been established with
the controller.
Firmware version—this indi‐
cates the current firmware
installed in the controller.
Current setup file in use.
Click on the “I” buons for help.
