Timer Stage1 Tab
Stage1 Timer, Timing Retard Control ‐ this seng configures the Stage1 Timer, +12V output to be On whenever Stage1 Nitrous
is On (Solenoids funconing). Check to enable.
If this seng is Off then the Timer1 output can be configured by selecng which control parameters are used to turn On the output.
When more than one control parameter has been selected all must meet the condions as configured before the output will funcon.
Example ‐ Acvaon Input Enabled and RPM Enabled, RPM On = 2000 and RPM Off = 4000, the Timer1 output will only be on when the
Acvaon Input is acve and the engine rpm is between 2000 and 4000 rpm.
This output supplies +12V when On.
This output may be used to drive an external relay with a load of no more than 1 amp. The relay can then be used to control another
stage of nitrous with no progressive ramp.
Timer Stage1 Configuraon ‐ check to enable which control parameters are used to deter‐
mine when the Stage1 Timer +12V output will be On. This output supplies +12V when On.
Any opons that are selected are combined to determine if the output should be on or off.
Note—the “Timing Retard Control” must be un‐checked (off) for these features to
be enabled.
Delay Timer ‐ these sengs control the Delay me and On me
for the Timer output.
Valid range ‐ 0.000 to 10.000 in .001 Second increments.
Engine RPM ‐ these sengs control the output based on Engine
RPM.
Valid range ‐ 0 to 16000 in 10 RPM increments.
Stage2 Nitrous Percent ‐ these sengs control the output
based on Stage2 Nitrous Percent.
Valid range ‐ 0.0 to 100.0 in .1 Percent increments.
Stage2 Fuel Percent ‐ these sengs control the output based on
Stage2 Fuel Percent.
Valid range ‐ 0.0 to 100.0 in .1 Percent increments.
Stage1 Nitrous Percent ‐
these sengs control the
output based on Stage1
Nitrous Percent.
Valid range ‐ 0.0 to 100.0
in .1 Percent increments.
Stage1 Fuel Percent ‐ these
sengs control the output
based on Stage1 Fuel Per‐
cent.
Valid range ‐ 0.0 to 100.0
in .1 Percent increments.
