Page #32 background imageLoading...
Page #32 background image
IDS 410/422 User's Manual
31
Parameter 25: Serial Port 2 Mode (4 [8 data bits, no parity] )
Enter the mode number from the table below to select the mode parameter in the mode
description column.
Mode Number Mode Description
1 7 data bits, no parity
2 7 data bits, even parity
3 7 data bits, odd parity
4 8 data bits, no parity
5 8 data bits, even parity
6 8 data bits, odd parity
Parameter 26: Serial Port 2 Baud Rate (1 [9600 baud])
Enter the baud number from the table below to select baud rate in the baud description
column.
 
1 9600 Baud
2 4800 Baud
3 2400 Baud
4 1200 Baud
5 600 Baud
6 300 (19.2k Baud *HS)
7 150 (38.4k Baud *HS)
Parameter 27: TX2 Control / Station ID (255 [single station])
Serial Port 2 can be used for continuous transmission of scale data or as a network buss or
for single station remote control.
Enter a 0 to enable continuous transmission of data (parameter 28).
Enter a station ID (1 to 254) for network buss configuration.
Enter 255 for single station remote control.
*High Speed version only.
