IDS 410/422 User's Manual
45
Function 68: Print Operation Parameters
Use function 68 to send the operation parameter data to the printer.
1. Hold the GROSS/NET key down and press the UNITS key to enter configure mode.
Enter CFG 68. The IDS 410/422 prompts "Print". Press the ENTER key to print the
operation parameters or press the CLEAR key to exit without printing.
Function 69: Diagnostic Tests
Use function 69 to access the IDS 410/422's built in diagnostic tests. See the chapter 7 -
"Diagnostic Tests" for more information on the diagnostic tests.
1 Hold the GROSS/NET key down and press the UNITS key to enter configure mode.
2 Enter CFG 69. The IDS 410/422 prompts "diA xx" where xx is the currently selected test
number. Enter a test number or press the ENTER key to use the displayed number.
3 The IDS 410/422 begins the selected test. Press the CLEAR key when the test is complete.
Test No. Hardware Tested Description
1 Serial Com. Port 1 display input data.
2 Serial Com. Port 1 display input error count.
3 Serial Com. Port 1 transmit data.
4 Serial Com. Port 2 display input data.
5 Serial Com. Port 2 display input error count.
6 Serial Com. Port 2 transmit data.
7 TTL I/O test Activates TTL 1-3 In and out.
8 A/D converter display raw conversion data.
9 Ram Memory test memory for errors.
10 Display turn on all LED's and display segments.
11 EAROM data Print the EAROM configuration data.
12 Serial Com. Port 1 Transmit/Receive loop-back test.
13 Serial Com. Port 2 Transmit/Receive loop-back test.
