… and fasten it by means of the hexagon socket set
screw (4).
6.2.3 Replacing Measuring Chamber
Precondition
Troubleshooting (measuring chamber) performed (→  42).
 Set the calibration value of the spare sensor with the
<CAL> switch on the electronics unit (5).
DIA
ADJ
CAL
HV-ST
ST
E
C
A
0
2
4
6
8
E
C
A
0
2
4
6
8
Calibration value
spare sensor
(measuring chamber cpl.)
8
5
