Infinity S601 Profile - Page 46

45
Ordercode: 41507
Infinity S601 Profile
Channel 41 – Angle Frame 1
0-255
Angle adjustment, 0-100%
Channel 42 – Angle Frame 1, 16 bit
Channel 43 – Position Frame 2
0-255
Position adjustment, 0-100%
Channel 44 – Position Frame 2, 16 bit
Channel 45 – Angle Frame 2
0-255
Angle adjustment, 0-100%
Channel 46 – Angle Frame 2, 16 bit
Channel 47 – Position Frame 3
0-255
Position adjustment, 0-100%
Channel 48 – Position Frame 3, 16 bit
Channel 49 – Angle Frame 3
0-255
Angle adjustment, 0-100%
Channel 50 – Angle Frame 3, 16 bit
Channel 51 – Position Frame 4
0-255
Position adjustment, 0-100%
Channel 52 – Position Frame 4, 16 bit
Channel 53 – Angle Frame 4
0-255
Angle adjustment, 0-100%
Channel 54 – Angle Frame 4, 16 bit
Channel 55 – Frame rotation
0-255
Frame rotation, 0-100%
Channel 56 – Framing macros CH6 and CH8 must be open
0-3
Not functional
4-255
Framing patterns
Channel 57 – Functions
0-5
Not functional
6-11
Pan reverse
12-17
Pan normal
18-23
Tilt reverse
24-29
Tilt normal
30-35
Pan/Tilt swop
36-41
Pan/Tilt normal
42-47
P/T blackout ON
48-53
P/T blackout OFF
54-59
Color wheel blackout ON
60-65
Color wheel blackout OFF
66-71
Rotating gobo wheel blackout ON
72-77
Rotating gobo wheel blackout OFF
78-83
Fans: Auto
84-89
Fans: Full
