InfiRay MINI MH25 V2 User Manual

2 3
1. OVERVIEW
The InfiRay Outdoor MINI MH25V2 is a compact, lightweight thermal imager
designed for handheld or helmet-mounted use. Its unique design allows for
seamless operation as a handheld monocular, and it can easily transition to a
helmet mount for hands-free use. The MH25V2 is powered by a 50hz 12 μm
sensor and features next-generation MATRIXIII processing for an unmatched
viewing experience. In addition to the features found on the original MH25,
the MH25V2 adds several highly-requested features including an upgraded
AMOLED display, an upgraded eyepiece, and onboard video and audio
recording.
2. FEATURES
• 12 μm high-performance thermal detector
• High image quality
• Aluminum/ABS housing
• Maximum detection range 1375 yards
• Rechargeable battery included
• HD 1280×960 AMOLED display
• High frame frequency: 50hz
• Stepped digital zoom from 1.0×to4.0×
• Built-in 32 GB storage to support
image capture and video recording
• Built-in motion sensor
• Bluetooth remote control
• Built-in Wi-Fi module
• Mobile device App compatible
• Automatic standby
• Multiple color palette options
• Picture in Picture (PIP)
• User-friendly interface
3. TECH SPECS
MINI MH25W
SENSOR
Resolution 640×512
Pixel Size 12 μm
Frame Rate 50hz
Image Processing MATRIX III
Core InfiRay Micro II 640
OPTICS
Objective Lens 25 mm f/1.0
Magnification 1×
Digital Zoom 4×, Stepped
Field of View 17.5° × 13.1°
Detection Range 1375 Yards
Display Type AMOLED
Display Resolution 1280×960
Color Palettes White Hot, Black Hot, Red Hot, Color
Mounting System MUM Rail
P.I.P. Ye s
Rangefinder Stadiametric
Eye Relief 20 mm
Diopter Range -4 to +3
ELECTRONICS
Onboard Recording Video and Image
Onboard Storage 32 GB
Data Connector USB-C, Analog Video Out
Data/Power Connector USB-C
Power Supply USB-C External, 16340 Battery (1+ Hour), 16650 Battery (2.5+ Hours)
Start Up Time <10 Seconds, Instant from Standby
PHYSICAL
Size 5.03” × 2.75” × 1.77”
Weight 12.1 Oz
ENVIRONMENTAL/WARRANTY
Warranty 5 Years
Housing Material Aluminum/ABS
Ingress Protection IP67
Operation Temperature 14°F~122°F
