34 35
SETTING MENU > STANDBY
Turn standby on / o
To conserve battery, the MH25V2
may be set to automatically enter
standby mode after 5minutes of
inactivity.
1. Rotate the Rotary Encoder to
select the Standby submenu
item.
2. Short press the Rotary
Encoder to toggle standby
on / o. Standby is o by default.
3. Long press the Rotary Encoder to save and return to the home screen.
4. When standby is turned on, the MH25V2 will automatically enter
standby mode after 5 minutes of inactivity.
5. When in standby mode, short press the Rotary Encoder to exit and
return to the home screen.
NOTES:
The MH25V2 will not enter standby if Wi-Fi, Bluetooth, or video
recording is on.
When standby is o, the thermal imager will operate until the battery
runs out.
24. BASIC INSPECTION
It is recommended to carry out a technical inspection before each use.
Please check the following:
The thermal imager appearance: there should be no cracks in the body
or visible damage.
The condition of the objective lens and eyepiece: there should be no
cracks, greasy spots, dirt, or other deposits on the lens.
The rechargeable battery should be fully charged.
The rotary encoder and Bluetooth remote control should be in working
order.
25. BASIC MAINTENANCE
Always replace the objective lens cap (1) after use to avoid damaging or
scratching the lens. Never touch the lens directly; oil from your skin can
damage the lens coating and surface.
Basic maintenance should be carried out at least twice a year and includes
the following steps:
Wipe the surface of the external metal and plastic components
with a clean, dry cotton cloth. Do not use chemical, corrosive, or
abrasive cleaners. Canned air may also be used to clean the external
components.
Clean the electric contacts and battery slots on the thermal imager
using a non-greasy organic solvent.
Check the lens and eyepiece. If necessary, remove any dirt or sand from
the optics; a non-contact cleaning method is preferred.
Cleaning the exterior of the lens should only be done with the included
microfiber lens cloth or a similar product. Only clean the lens when
it is visibly soiled. Frequent wiping or cleaning can degrade the
anti-reflective lens coating.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InfiRay MINI MH25 V2 and is the answer not in the manual?

InfiRay MINI MH25 V2 Specifications

General IconGeneral
Frame Rate50Hz
Field of View10.5° × 8°
Weight<350g
FocusManual
InterfaceType-C
Objective Lens25mm
Sensor TypeUncooled microbolometer
Spectral Range8-14μm
Display Size0.39"
Operating Temperature-20℃~+50℃
Storage Temperature-40°C to +60°C
