26 27
DEVICE MENU > WIFI
Turn Wi‑Fi on / o
Turn on Wi-Fi to manipulate the
MH25V2 via the InfiRay Outdoor
App.
1. Rotate the Rotary Encoder
to select the Wi-Fi submenu
item.
2. Short press the Rotary
Encoder to toggle Wi-Fi on /
o. Wi-Fi is o by default.
3. When Wi-Fi is on, the Wi-Fi icon appears in the status bar.
4. Long press the Rotary Encoder to save and return to the home screen.
DEVICE MENU > BLUETOOTH
Turn Bluetooth on / o
The Bluetooth function enables
connectivity to the included
Bluetooth remote control. See
page21 for remote control
connection and usage instructions.
1. Rotate the Rotary Encoder
to select the Bluetooth
submenu item.
2. Short press the Rotary
Encoder to toggle Bluetooth on / o. Bluetooth is o by default.
3. When Bluetooth is on, the Bluetooth icon appears in the status bar.
4. Long press the Rotary Encoder to save and return to the home screen.
Calculate the approximate distance of the observed object:
1. Rotate the Rotary Encoder to expand or contract the space between the
horizontal lines until they touch the top and bottom edges of the target
object.
a. Rotate clockwise to expand the space between the lines.
b. Rotate counterclockwise to shrink the space between the lines.
c. As you adjust the space between the horizontal lines, the
rangefinder distance values on the right side of the screen are
automatically recalculated.
2. Long press the Rotary Encoder to turn o the stadiametric rangefinder.
23. MAIN MENU OPTIONS AND
DESCRIPTIONS
Menu and submenu options from left to right are:
Main Menu: Device, Function, Calibration, Setting.
Device Menu: Wi-Fi, Bluetooth, Msensor.
Function Menu: Video Output, Rangefinder, PIP.
Calibration Menu: Time.
Setting Menu: Factory Reset, Sharpness, NUC Mode, Standby.
Menu option details, descriptions, and navigation instructions are listed in
order on the following pages.
Device Menu
Adjust the device settings
1. Long press the Rotary Encoder to enter the main menu. The Device
Menu is selected by default.
2. Rotate the Rotary Encoder to move through the Device submenu items,
Wi-Fi, Bluetooth, and Msensor.
