4 5
4. ACCESSORIES
The MINI MH25V2 thermal imager ships with everything you need to get out
and hunt.
• MINI MH25V2
• Standard Eyeguard for MINI
• Bluetooth Remote Control
• USB-C to Analog RCA/USB Cable 36”
• 16340 Rechargeable Battery
• Micro-USB Cable
• Adapter for 16650 Battery*
• USB Power Adapter
• Soft Case and Shoulder Strap
• Lens Cloth
• User Manual
*16650 battery is optional/not included.
Replacement accessories are available for purchase. Contact 800-769-7125
or irayusa.com/support.
5. COMPONENTS AND CONTROLS
8 9
1 2 3 4 5 6 7
1 Objective Lens Cap
2 Objective Lens Focus Ring
3 Battery Cover
4 USB-C Port
5 Rotary Encoder
6 Eyepiece / Diopter Adjustment Ring
7 Eyeguard
8 MUM Rail Interface
9 Dovetail Interface for Optional IRAY-AC49
