InfiRay RL42 User Manual

Field of View, degrees
6.3°x 4.7°
5.3°x 4.0°
Magnification, x
4~16
2.8~11.2
E-zoom, x
4 / 8 / 12 / 16
2.8 / 5.6 / 8.4 / 11.2
Eye relief, mm
55
Exit pupil diameter, mm
6
Diopter Adjustment, D
-4~+4
Detection Range, m
(Target size: 1.7mx0.5m, P(n)=99%)
2197
2594
Display
Type
AMOLED
Resolution, pixels
1024*768
Size, inch
0.39
Power Supply
Battery Type / Capacity / Output
Voltage
Li-Ion Battery Pack IBP-1 / 3600mAh / DC3.7V
Power Supply
3V~4.2V
External Power Supply
5V (Type C USB)
Operational Characteristics
Max. Operating Time (at t=22℃), h
★
6
Max. Recoil Power on Rifled
Weapon, g/s²
1000
Degree of protection, IP code
IP67
Amount of built-in memory, Gb
32
Operating Temperature Range, ℃
-20~+50
Laser Rangefinder
Optional
Weight, g
820
830
Dimension, mm
250x65x58
250x61x58
Characteristics of Rangefinder
Wavelength, nm
905
Max. Measuring Range, m/y
★★
1000/1094
Measurement Accuracy, m
±1
* The actual operating time depends on the intensity of using Wi-Fi, video recorder, laser
rangefinder.
* * Depends on the characteristics of the object under observation and environmental conditions.

InfiRay RL42 Specifications

General

Sensor Resolution	384x288
Pixel Size	12 μm
Frame Rate	50 Hz
IP Rating	IP67
Type	Handheld
Battery	Lithium-ion
Battery Type	Lithium-ion
Operating Temperature	-20°C to +50°C
