4. Components and buttons
1. Lens Cover
2 Object Lens Focusing
Ring
3 Power Button
4 Up button/Zoom in
5. Menu/M button
6. Down
Button/Photographing
Button
7. Eye piece focusing ring
8. Eye Cup
9. Laser Rangefinder
(Optional)
9a. Laser launch port
9b. Laser receive port
9c. Laser indicator port
10. TypeC port
11. Battery pack
12. Battery pack ring-pull
13. Battery pack jar
Button function Description
Button
Status/
Current
operation
mode
Press
Hold Down
Power Button
OFF
——
Switch On
