20
English
Installation
XGA SHORT THROW
Diagonal length
(inch) size of
4:3 Screen
Screen Size W x H Projection Distance (D)
Offset (Hd)
(m) (inch) (m) (feet)
Width Height Width Height wide tele wide tele (m) (inch)
40 0.81 0.61 31.89 24.02 0.5 0.5 19.69 19.69 0.09 3.60
50 1.01 0.76 39.76 29.92 0.63 0.63 24.80 24.80 0.11 4.49
60 1.22 0.91 48.03 35.83 0.75 0.75 29.53 29.53 0.14 5.37
70 1.42 1.07 55.91 42.13 0.88 0.88 34.65 34.65 0.16 6.32
80 1.63 1.22 64.17 48.03 1 1 39.37 39.37 0.18 7.20
90 1.83 1.37 72.05 53.94 1.13 1.13 44.49 44.49 0.21 8.09
100 2.03 1.52 79.92 59.84 1.25 1.25 49.21 49.21 0.23 8.98
120 2.44 1.83 96.06 72.05 1.5 1.5 59.06 59.06 0.27 10.81
150 3.05 2.29 120.08 90.16 1.88 1.88 74.02 74.02 0.34 13.52
200 4.06 3.05 159.84 120.08 2.51 2.51 98.82 98.82 0.46 18.01
250 5.08 3.81 200.00 150.00 3.13 3.13 123.23 123.23 0.57 22.50
300 6.1 4.57 240.16 179.92 3.76 3.76 148.03 148.03 0.69 26.99
 This table is for user’s reference only.
