5
Connector panel
The projector provides both computer and video connection options, including:
• VGA computer
• Composite video
• USB mini B connector. This USB connectio
n provides slide advance (and
mouse control when used with an optional remote control only) and
LiteBoard™ Wand control.
• Monitor out, for VGA pass through to an external monitor.
• Audio input for video and computer.
• Audio L/R for video and computer.
• Audio output to external speakers.
• Microphone, for connecting to a dynamic microphone.
• 5 volt DC output. The coaxial connector
accepts a 2.1mm x 5.5mm plug and
provides a constant 5 volt, 2 amp DC output when the projector is on. It is
designed to provide power for an InFocus LiteShow wireless device, which
allows wireless projection. More information can be found on our website at
www.infocus.com or at your retailer or dealer.
USB
