Indicates the load level in output: 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates that the load or output is short.
Operation mode information
Indicates that the UPS is connected to the mains.
Indicates that the battery is working.
Indicates that the bypass circuit is working.
Indicates that the Inverter circuit is working.
Indicates that the output is working.
Indicates Battery capacity: 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates a battery fault.
Indicates low battery level and low battery voltage.
Input & Battery voltage information
Indicates the input voltage or frequency or battery voltage.
Vac: Input voltage, Vdc: battery voltage, Hz: input frequency
