6. External battery bank
E6 LCD RT 5000: The batteries are fitted inside UPS bank.
For all other UPS from 6000 to 10kVA, the batteries are fitted inside an external battery bank.
Please refer to the battery bank user’s manual for a correct procedure.
Refer to the following chart for external battery bank connection.
Model Maximum Current Conductor Section
6KVA 25A 6 mm²
8KVA 33A 6 mm²
10KVA 41A 6 mm²
6/8000VA model
5000VA model
10KVA model
