7. Specifications
E6 LCD 5000 RT E6 LCD 6000 RT E6 LCD 8000 RT E6 LCD 10K RT E6 LCD 10K RT TM
NPUT
Voltage Range (VAC) 160 - 280 277 - 485
Frequency (Hz) 45 / 65 Hz
Number of phases Single phase + ground
Three phase, R, S, T +
Neutral + Ground
Input Power factor > 0,99 (full load)
THD <7% <30%
OUTPUT
Voltage Range (Vac) 200 / 208 / 220 / 230 / 240 adjustable (120 VAC optional)
Voltage adjustment Nominal voltage + 1%, + 2%, + 3%, - 1%, - 2%, - 3%
Voltage regulation ± 2%
Capacity 5000 VA / 4500 W 6000 VA / 5400 W 8000 VA / 7200 W 10000 VA / 9000 W 10000 VA / 9000 W
Power Factor 0,9
Output wave form Sine wave, THD <3% (from 0 up to 100% of load)
Frequency stability ± 0,2% (battery mode)
Frequency regulation +/-1Hz or +/-3Hz (programmable by user)
Transfer time 0 ms
Crest factor 3:1
Efficiency Up to 90% (normal mode) ; Up to 95% (Eco mode)
Nominal autonomy > 3 min > 8 min > 5 min
Cold start Yes
BATTERY
Capacity 12V / 5 Ah 12 V/ 7 Ah 12 V/ 7 Ah 12 V/ 9 Ah
Quantity 20
Voltage (V) 240
Recharge time 4 hours at 90% 5 hours at 90%
DISPLAY
Status on LCD and LED Normal, Battery, Eco mode, Bypass, Battery low, Default battery, Overload and Inverter default
Data specified on LCD Input voltage and frequency, Output voltage, Frequency voltage, Charge level, Voltage battery, internal Temperature
Self-diagnostics In mains mode, from control panel , by software and auto test/ 24h
PROTECTION
Short circuit Off mode immediately
Over heating Mains mode : Bypass Transfer - Battery Mode : Automatic shutdown
Low battery Alarm and automatic stop
EPO Switch off immediately
Battery Electronic system of management of battery discharge
Leakage current < 3 mA in full load
ALARMS
Acoustics & display Mains default / Low battery / Overload / Environment default
PHYSICALS CHARACTERISTICS
Mechanicals dimensions
(H x W x D) mm
176 x 440 x 680 (4U) 88 x 440 x 680*(2U) 132 x 440 x 680* (3U) 132 x 440 x 680* (3U)
Net weight + battery weight 52 Kg 24+68 Kg 26+68 Kg 26+68 Kg 52 Kg
Input & Output connectors Terminal board
ENVIRONMENT
Operating temp, range 0-40°C
Warning temperature Battery design for use at 25°C. A higher ambient temperature will decrease its life span
Altitude 0-2000 m up to 40°C / 3000 m up to 35°C
Humidity 90% max without condensation
Noise < 50dB (at 1 m)
INTERFACE COMPUTER
Type Standard RS 232
Slots Second RS 232, USB, RS 485, relay card, SNMP/ Web card
compatible systems Windows 95/98/NT/2000/XP/Vista, Novell Netware, Linux etc
COMPLIANCE
Security EN62040-1-1, UL1778
Standard EMC IEC/EN 62040-2 class A ; IEC/EN 61000-4-2/-3/-4/-5/-6/-8 ; IEC/EN61000-2-2 ; IEC/EN 61000-3-2/-3
Marking CE, cUL
*UPS without battery bank
