8.1 Output Power Curves
The curves that follow depict the changes for each RF mode at specific power
settings.
Figure 08-1: Morpheus8 Body Output Power versus Impedance
The following curves depict Peak Voltage vs. Power Settings.
Figure 08-2: Output Power Versus Impedance
4.81 4.81 4.81 4.81 4.81 4.81 4.81 4.81
2.34 2.34 2.34 2.34 2.34 2.34 2.34 2.34
0.00
1.00
2.00
3.00
4.00
5.00
6.00
50 100 200 300 400 500 600 700
Power [W]
Load Resistance [Ω]
Morpheus8
Full Power
Half Power
