Morpheus8 Body Applicator Operator
Manual
Section 4: Device Description
4.3 Sound Indicator
▪ A periodic tone indicates that RF is delivered.
▪ A warning sound tone indicates Bad Coupling.
4.4 Handpieces
Morpheus8 Body Handpieces (Error! Reference source not found.) comprise motor
with actuator pushing needle electrodes out to pre-determined depth up to 7mm.
The tip (Figure 4-7) is connected or disconnected with the Handpiece.
Figure 4-6: Morpheus8 Body Handpiece
Figure 4-7: Morpheus8-40 Pins Tip (Body)
The tips comprise 40 needles that are coated along with an insulating
material except the distal 0.5mm edge (Figure 4-8). Note the insulation that
leaves only the 0.5mm tip exposed.
The Handpiece handle is made of plastic and has an ergonomic design for
easy treatment, with high visibility of the treated area.
