Morpheus8 Body Applicator Operator
Manual
Section 4: Device Description
15 of 34
• Burst mode - the energy is delivered automatically at
up to 3 different tissue layers within the same single
cycle. When activated, the needles are deployed into
the tissue and when retracts the needles are stopped
every 2 mm in subdermal space and RF energy is
delivered. For example, when choosing treatment
depth of 7mm the energy will be delivered within the
same pulse cycle, first at 7 mm, then 5 mm, then 3 mm.
When choosing 6 mm depth, the energy will be
delivered at 6 mm, then 4 mm and then 2mm.
Depth Setting
Burst Mode
Depth of RF Energy Release
7mm
7mm, 5mm, 3mm
6mm
6mm, 4mm, 2mm
5mm
5mm, 3mm
4mm
4mm, 2mm
When switching from Cycle/Fixed Mode with Depth Settings 1, 2
or 3mm to Burst Mode the Depth Settings automatically will be
adjusted to 4mm
Repetition
Select between single pulse delivery at Footswitch pressing and
autorepeat mode with predetermined pulse repletion rate
Counter Reset
Counter can be reset number of pulses per zone.
Pulse Counter
Shows number of pulses delivered on one zone and total
number of pulses from the beginning of the treatment.
System Mode
The System has three treatment modes: Standby, Ready, and
Active.
Standby mode allows the user to set treatment parameters.
Activation of energy is not allowed in Standby mode.
In Ready mode, the system is waiting for a signal from the foot
switch to activate the energy. Any attempt to change the
treatment settings switches the system to Standby mode.
When the signal from the Footswitch is indicated, the system
switches to Active mode. Any attempt to change the treatment
settings switches the system to Standby mode.
Main Menu
Return to the Main Menu to select another applicator and
change the applicator if needed.
