15. TECHNICAL DESCRIPTION
15.1 SPECIFICATIONS
Inogen Rove 6 Portable Oxygen Concentrator (Model # IO-501)
Mains Isolation Remove both the DC input cord from device as well as the battery pack.
Dimensions with standard battery 7.2 x 3.3 x 8.2 in (18.3 x 8.3 x 20.5 cm)
Dimensions with extended battery 7.2 x 3.3 x 9 in (18.3 x 8.3 x 22.9 cm)
Weight with standard battery 4.8 pounds (2.2kg)
Weight with extended battery 5.8 pounds (2.6kg)
Nominal sound level 39 dBA typical at setting 2 (MDS-Hi)
Maximum system sound power of 62 dBA
Maximum system sound pressure of 54 dBA
Typical lowest alarm sound pressure of 62.3 dBA (Measured in the carry bag)
Typical highest alarm sound pressure of 67.5 dBA (Measured in the carry bag)
(Sound pressures measured at 1 meter per ISO 3744
Warm up time 2 minutes
Oxygen concentration* 90% + 6% and - 3% at all settings
Inspiratory trigger pressure sensitivity <0.12 cm H20
Flow control settings Pulse dose setting 1,2,3,4,5,6
Maximum outlet pressure < 22 PSI
18.7 PSI (129 kPa) ± 10%
AC Power 100 to 240 VAC, 50 to 60 Hz
Autosensing 2.0 – 1.0A
DC Power 13.5-15.0VDC,100W
Max voltage: 12.0 to 16.8 VDC (+ 0.5)
Battery type Lithium ion
Rechargeable battery: 12.0 to 16.8 VDC (± 0.5V)
Battery re-charge time Standard (BA-500 & BA-508): up to 3 hours
Extended (BA-516): up to 4 hours
Operating temperature** 41 to 104˚F (5 to 40˚C)
Operating humidity 15% to 90%, non-condensing
Operating atmospheric pressure 70 kPA to 106 kPA
Operating altitude** 0 to 10,000 ft (0 to 3048 meters)
Shipping and storage temperature -13 to 158˚F (-25 to 70˚C)
Shipping and storage humidity Up to 90%, non-condensing
Store in a dry environment.
Measurement uncertainties: Pulse volumes: ± 15% of rated volume
Pressure: ± 0.03 psig (General) / ± 0.05 cm H2O (Inspiratory Trigger Sensitivity)
Oxygen concentration: ± 3% (not accounting for temperature, barometric
pressure, and time from measurement device calibration)
*Based on atmospheric pressure of 101.3 kPa (14.69 psi) at 20˚ C (68˚ F) & Dry (STPD).
**Operating outside of these operational specifications can limit the concentrator’s ability to meeting Oxygen
Concentration specification at higher liter flow settings.
