Introduction
Name Function
AC input 100 VAC to 240 VAC input
Protective ground (connected to the ground wire of the AC input power)
Function ground (connected to the system housing)
The DC output terminal must meet the following requirements:
Terminal Symbol Function Remarks
24 V 24 V DC output -
5 V 5 V DC output
If the module does not have the 5 V DC output
,
this terminal is not
connected in the module.
GND DC output ground -
GND DC output ground -
3 Dimensions (mm)
50.0
90.
0
95.0
AM600
Risk of electric shock
小心触电
Figure 3-7 Dimensions of the power module
