Introduction
Item AM600-0016ETP AM600-0016ETN AM600-0032ETN
OFF max. leakage
current
Below 0.5 mA
ON response time Below 0.5 ms (hardware response time)
OFF response time Below 0.5 ms (hardware response time)
Max. load
Resistive
load
0.5 A/channel
,
2 A/common
Inductive
load
12 W/24 VDC (total)
Lamp load 2 W/24 VDC (total)
Isolation method Opto-couplers isolation
Output action display Output indicator ON when opto-coupler driving is applied
Short circuit-proof
output
Yes (The current is limited to
the range of 1 A to 1.7 A when
short circuit protection is
applied.)
None Yes
■
Basic speci󶍾cations of the relay output module
Item AM600-0016ER
Output channel 16
Output connecting mode 16+2 (COM) channel wiring terminal
Power supply of the module
[1]
24 VDC (–15% to +20%)
Output Type Relay output
Output mode Dry contact
Voltage of the output control
circuit
110 VAC to 220 VAC
Power consumption of the internal
5 V power supply
65 mA (typical value)
Rated current of relay 240 VAC/24 VDC
,
2 A
OFF max. leakage current -
ON response time Below 20 ms (hardware response time)
OFF response time Below 20 ms (hardware response time)
Max. load
Resistive load Single-channel 1 A/channel
Lamp load Single-channel 30 W
Inductive load 220 VAC
,
2 A/1 channel
Capacitive load Not recommended
Isolation method Mechanical isolation
Output action display Output indicator ON when the relay is excited
[1] The power supply of the module is connected through an independent 2-pin terminal.
