-60-
Introduction
A
B
Figure 4-9 Plug the module into the DIN guide rail
3) Push up the DIN guide rail installation hooks of the module until they click to plug the module to
the DIN guide rail. If your 󶍾ngers cannot reach the DIN guide rail installation hooks
,
use a tool
,
for
example
,
a screwdriver.
Figure 4-10 Plug in the hooks in the shown direction
CAUTION
◆
Do not install by sliding the module from the end of the DIN guide rail; otherwise
,
the metal
parts on the rear side of the module may be damaged.
