Inovance IS620P Series Manual

6 Parameter Table
6
- 75 -
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H03-13 DI6 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-14 DI7 function selection 0 to 37 - 3
St Ru
-
H03-15 DI7 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-16 DI8 function selection 0 to 37 - 31
St Ru
-
H03-17 DI8 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-18 DI9 function selection 0 to 37 - 0
St Ru
-
H03-19 DI9 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-34
DI function (active after
power-on) allocation 3
0 to 0xFFFF
Bit0: FunIN.33; Bit1: FunIN.34
……Bit15: FunIN.48
- 0
Po Ru
-
H03-35
DI function (active after
power-on) allocation 4
0 to 0xFFFF
Bit0: FunIN.49; Bit1:FunIN.50
……Bit15: FunIN.64
- 0
Po Ru
-
H03-50 AI1 offset -5000 to 5000 mV 0
Im Ru
-
H03-51 AI1 lter time constant 0 to 655.35 ms 2.00
Im Ru
-
H03-53 AI1 dead zone 0 to 1000.0 mV 10.0
Im Ru
-
H03-54 AI1 zero drift -500.0 to 500.0 mV 0.0
Im Ru
-
H03-55 AI2 offset -5000 to 5000 mV 0
Im Ru
-
H03-56 AI2 lter time constant 0 to 655.35 ms 2.00
Im Ru
-
H03-58 AI2 dead zone 0 to 1000.0 mV 10.0
Im Ru
-
H03-59 AI2 zero drift -500.0 to 500.0 mV 0.0
Im Ru
-
H03-80
Speed corresponding to 10
V
0 to 9000 RPM
3000
RPM
Im St
-
H03-81
Torque corresponding to
10 V
1.00 to 8.00 times of rated torque 1.00 1.00
Im St
-
