6 Parameter Table
6
- 74 -
Function
Code
Parameter Name Setting Range Unit Default ET
Pro
CM
H02-39
Maximum braking current at
short-circuit
0 to 3000 0.1% 1000 Im
St
S
Group H03: Input Terminal Parameters
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H03-00
DI function (active after
power-on) allocation 1
0–0xFFFF
Bit0: FunIN.1; Bit1: FunIN.2
……Bit15: FunIN.16
- 0
Po Ru
-
H03-01
DI function (active after
power-on) allocation 2
0–0xFFFF
Bit0: FunIN.17; Bit1: FunIN.18
……Bit15: FunIN.32
- 0
Po Ru
-
H03-02 DI1 function selection 0 to 37 - 14
St Ru
-
H03-03 DI1 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-04 DI2 function selection 0 to 37 - 15
St Ru
-
H03-05 DI2 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-06 DI3 function selection 0 to 37 - 13
St Ru
-
H03-07 DI3 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-08 DI4 function selection 0 to 37 - 2
St Ru
-
H03-09 DI4 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-10 DI5 function selection 0 to 37 - 1
St Ru
-
H03-11 DI5 logic selection
Input polarity: 0 to 4
0: Low level valid
1: High level valid
2: Rising edge valid
3: Falling edge valid
4: Rising edge and falling edge both valid
- 0
St Ru
-
H03-12 DI6 function selection 0 to 37 - 12
St Ru
-
