9 Step 2: Set Motor Parameters
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F1-00
Motor type selection
0: Common asynchronous motor
1: Variable-frequency asynchronous motor
N.A. 0
F1-01
Rated motor power
0.1 to 7.5
kW
Model
dependent
F1-02
Rated motor voltage
1 to 1000
V
Model
dependent
F1-03
Rated motor current
0.01 to 655.35
A
Model
dependent
F1-04
Rated motor frequency
0.01 to Max. frequency
Hz
Model
dependent
F1-05
Rated motor speed
1 to 65535
RPM
Model
dependent
9 Step 3: Set Frequency Reference
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F0-03
Main frequency source
X selection
0: Digital setting F0-08
(non-retentive at power down)
1: Digital setting F0-08
(retentive at power down)
2: AI1
3: Reserved
4: Reserved
5: Pulse reference (DI5)
6: Multi-reference
7: Simple PLC
8: PID
9: Communication reference
N.A. 0
F0-04
Auxiliary frequency
source Y selection
The same as F0-03 (Main frequency source X
selection)
N.A. 0
