9 Step 11: Set DC Injection Braking If Needed
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F6-00
Start mode
0: Direct startup
1: Reserved
2: Pre-excited startup (asynchronous motor)
N.A. 0
F6-05
ƿ
DC Injection Braking 1
level
0 to 100
% 0
F6-06
ƿ
DC Injection Braking 1
active time
0.0 to 100.0
s 0.0
F6-11
DC Injection Braking 2
frequency threshold
0.00 to Max. frequency
Hz 0.00
F6-12
DC Injection Braking 2
delay time
0.0 to 36.0
s 0.0
F6-13
DC Injection Braking 2
level
0 to 100%
% 0
F6-14
DC Injection Braking 2
active time
0.0 to 36.0
s 0.0
ƿ
: Only when F6-00=0, the Function codes F6-05 and F6-06 are relative to DC Injection Braking 1.
9 Step 12 : Set Pre-Excitation If Needed
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F6-00
Start mode
0: Direct startup
1: Reserved
2: Pre-excited startup (asynchronous motor)
N.A. 0 2
F6-05
ƿ
Pre-excitation level
0 to 100
%
0
F6-06
ƿ
Pre-excitation active
time
0.0 to 100.0
s 0.0
ƿ
: Only when F6-00=2, the Function codes F6-05 and F6-06 are relative to Pre-excitation.
