Product Information MD280/MD280N User Manual
Table 2-6 External Reactor Dimension Table ˄mm˅
Inverter Mode A B C D E F G
Moun
ting
Hole
Connectio
n Diameter
Hole of
Copper
Medal
MD280T75G/90P ǃ
90G/110P ǃ
110G/132P
160 190 125 161 192 255 195 10*15 ij12
MD280T132G/160Pǃ
160G/200P
160 190 125 161 192 255 195 10*15 ij12
MD280T200G/220Pǃ
220G/250P
190 230 93 128 250 325 200 13*18 ij15
MD280T250G/280Pǃ
280G/315P
190 230 93 128 250 325 200 13*18 ij15
MD280T315G/355Pǃ
355G/400P ǃ
400G/450P
224 250 135 165 260 330 235 12*20 ij14
Caution: Non-standard may be ordered for special requirements.
*External DC reactor installation mode:
MD280 series inverter of more than 75kW produced by Inovance all
employs standard external DC reactor, which is packed in independent
wooden box and delivered together with the inverter. When mounting the
inverter, the user needs to remove the short circuit bus between the
terminals P and (+) of the main circuit of the inverter and then connect the
DC reactor between P and (+). There is no polarity between the reactor
terminal and the inverter terminals P and (+). After the DC reactor is
mounted, the short circuit bus between P and (+) will not be used.
