Inovance MD280 Series - Group F1 Motor Parameters and V;F Control

Parameter Description MD280/MD280N User Manual
- 118 -
Auxiliary frequency
source offset digital
setup
Factory
default value
0.00Hz
F0-20
Setup range 0.00Hz to Maximum frequency F0-04
It is valid only at the time of frequency source overlap reference.
Group F1 Motor Parameter, V/F Control Parameter
Rated power
Factory defult
value
Model dependent
F1-00
Setup range 0.2kW to1000.0kW
Rated voltage
Factory defult
value
Model dependent
F1-01
Setup range 0V to 480V
Rated current
Factory defult
value
Model dependent
F1-02
Setup value 0.1A to 6553.5A
Rated frequency
Factory defult
value
Model dependent
F1-03
Setup range
0.00Hz to maximum frequency
˄F0-04˅
Caution
1ǃ Please set the parameters according to the nameplate parameters of
the motor.
2ǃTo ensure the control performance, the motor shall be configured
according to the standard configuration of the motor. If the motor
power has significant difference with the configuration of the standard
motor, the control performance of the inverter may be degraded.
3ǃWhen Modify the rated power, the drive power estimates under
the rated current, no-load current, stator resistance. Therefor, please
set the rated power, and then set the rated current, no-load current,
stator resistance.
V/F curve setup
Factory defult
value
0
F1-04
Set
0 Straight V/F curve
